Product name: Modular Welding Table / 2D
Series: D28 & D16
Technical parameter:
Modular welding table —— D28 series Modular welding table —— D16 series
►Be made of welding steel. ► Be made of welding steel.
►1 precision machined working surface ► 1 precision machined working surface
►Hole diameter: 28mm ► Hole diameter: 16mm
►Grid lines: 100mm*100mm ► Grid lines: 50mm*50mm
►Hole pitch: 100mm ► Hole pitch: 50mm
►Material thickness: approx.23mm ► Material thickness: approx.14mm
►Be reinforced on the underneath side by ribs. ► Be reinforced on the underneath side by ribs.
Specification as below:
Product features:
► Modularity and flexibility.
Can be connected and changed arbitrarily according to the shape of workpiece.
► High precision.
The precision can reach decimillimetre(dmm) for fixing and clamping.
► Quick fixing and clamping.
Only spending a few minutes to fix and clamp workpieces from one to another.
► Ease to operate.
Only 2 hours, any worker can learn how to use it quickly.
► High price-performance ratio.
1 set of modular flexible fixture can replace all traditional dedicated fixtures.
Saved a lot of time, labor, material resources and funds for enterprises.
► Clean, tidy and environmental Friendly.
Compared with mountains of rusty dedicated fixtures, modular flexible fixtures are the optimal choice.
► Other description:
3D Welding table, Welding table, Welding clamping system, Welding clamp table, Welding jig table, Welding fixture.
|
